Camera IP Speed Dome hồng ngoại 2.0 Megapixel HILOOK PTZ-P332ZI-DE3

Model

PTZ-P332ZI-DE3

Smart Features

Basic Event Detection

Motion Detection, Video Tampering Detection, Exception

Smart Detection

Audio Exception Detection, Intrusion Detection, Line Crossing Detection

Smart Record

ANR (Automatic Network Replenishment)

ROI

Main stream supports eight fixed areas.

Smart Image Enhancement

HLC/BLC/3D DNR/Regional Exposure/Regional Focus

Lens

FOV

Horizontal field of view: 120° to 56.6° (wide - tele),Vertical field of view: 61.8° to 31.7° (wide - tele),Diagonal field of view: 149° to 65° (wide - tele)

Focal Length

2.8 mm to 12 mm, 4× optical zoom

Zoom Speed

Approx.5.4 s (optical, wide - tele)

Working Distance

10 mm to 1500 mm (wide - tele)

Aperture Range

F2.0 to F2.4


Max. Resolution

Main stream:,50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480, 352 × 288),60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)

Network

Security Measures

User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering

Network Storage

Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB

Protocols

IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, Bonjour

API

Open-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform

Simultaneous Live View

Up to 4 × 4 channels

User/Host

Up to 32 users,3 levels: Administrator, Operator and User

Client

iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect

Web Browser

IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51

Camera Module

Image Sensor

1/2.8-inch progressive scan CMOS

Min. Illumination

Color: 0.05 Lux @(F2.0, AGC ON),B/W: 0.01 Lux @(F2.0, AGC ON),0 Lux with IR

White Balance

Auto/ Manual/ ATW (Auto-Tracking White Balance)/ Indoor/ Outdoor/ Fluorescent Lamp/ Sodium Lamp

Gain

Auto/ Manual

Shutter Time

50Hz: 1/25s to 1/30,000s
60Hz: 1/30s to 1/30,000s

Day & Night

IR Cut Filter

Digital Zoom

8x

Privacy Mask

8 programmable privacy masks

Focus Mode

Semi-automatic/Manual

WDR

Digital WDR

Interface

Audio Input

1-ch audio input

Audio Output

1-ch audio output

Network Interface

1 RJ45 10 M/100 M Ethernet

Dual-VCA

Support

Supplement Light

IR Distance

Up to 10 m IR (radius)

General

Material

PC + ABS & Aluminum alloy

Dimensions

Φ 183 mm × 133 mm (Φ 7.20' × 5.24')

Weight

Approx. 0.9 kg (1.98 lb)

Protection Level

TVS 2000V Lightning Protection, Surge Protection and Voltage Transient Protection

Power

12 VDC, 2.0 A & PoE (802.3 at), 42.5 to 57 VDC, 0.6 A, class 4 Max.24 W (Max. 6 W for IR)

Working Temperature

-10°C to 50°C (14°F to 122°F)

Working Humidity

≤ 90%

PTZ

Movement Range (Pan)

Pan: 0° to 350°;

Pan Speed

Pan speed: 0.1°/s to 30°/s (configurable), preset speed: 30°/s

Movement Range (Tilt)

Tilt: 0° to 90°

Tilt Speed

Tilt speed: 0.1°/s to 30°/s (configurable), preset speed: 30°/s

Proportional Zoom

Support

Presets

300

Power-Off Memory

Support

PTZ Status Display

Support

Preset Freezing

Support

Scheduled Task

Preset/Dome Reboot/Dome Adjust

PTZ Linkage

Support

Compression Standard

Video Compression

Main stream: H.265/H.264/MJPEG,H.264: Main Profile/High Profile

Video Bitrate

32 Kbps to 8192 Kbps

Audio Compression

G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2

Audio Bitrate

G.711alaw/G.711ulaw: 64 Kbps,G.722.1/G.726: 16 Kbps,MP212: 32 Kbps/64 Kbps/128 Kbps

SVC

Support
