CISCO ASA5525-K9
Liên hệ
- Mã sản phẩm: CISCOASA5525-K9
Digitechjsc cam kết
100% sản phẩm chính hãng, đầy đủ CO, CQ
100% giá cạnh tranh so với thị trường
Chính sách bán hàng và bảo hành
Giao hàng trên toàn quốc
Hỗ trợ các đại lý và dự án
Bảo hành, đổi trả nhanh chóng
Hỗ trợ kỹ thuật chuyên nghiệp
Chính sách hậu mãi đầy hấp dẫn
- 750 IPSec VPN peers, up to 2 Gbps stateful inspection throughput, 500,000 Concurrent Connections.
- Cloud- and Software-based Firewall services, 3DES/AES, 2 SSL VPN peers.
- 8 copper GE ports, 1 copper GE management port, 1 expansion slot.
- Cisco Application Visibility and Control (AVC), Cisco Web Security Essentials (WSE).
- Active/Active, Active/Standby high availability, 200 Vlans.
- 8 GB memory, 8 GB flash.
ASA5525-K9 Specification
ASA5525-K9 Specifications |
|
|
Feature |
ASA5525-K9 |
|
Stateful Inspection Throughput (Maximum) |
2 Gbps |
|
Stateful Inspection Throughput (Multiprotocol) |
1 Gbps |
|
IPS Throughput |
600 Mpbs |
|
Next-Generation Throughput(Multiprotocol) |
650 Mbps |
|
3DES/AES VPN Throughput |
300 Mbps |
|
Users/Nodes |
Unlimited |
|
IPsec VPN Peers |
750 |
|
Cisco Cloud Web Security Users |
4,000 |
|
Premium AnyConnect VPN Peers(Included/Maximum) |
2/750 |
|
Concurrent Connections |
500,000 |
|
New Connections/Second |
20,000 |
|
Virtual Interfaces (VLANs) |
200 |
|
Security Contexts (Included/Maximum)6 |
2; 20 |
|
High Availability |
Active/Active and Active/Standby |
|
Expansion Slot |
1 interface card |
|
User-Accessible Flash Slot |
0 |
|
USB 2.0 Ports |
2 |
|
Integrated I/O |
8 GE Copper |
|
Expansion I/O |
6 GE Copper or 6 GE SFP |
|
Serial Ports |
1 RJ-45 console |
|
Solid State Drive |
1 slot, 120 GB MLC SED |
|
Memory |
8 GB |
|
Minimum System Flash |
8 GB |
|
System Bus |
Multibus architecture |
|
Temperature |
23 to 104°F (-5 to 40°C) |
|
Relative Humidity |
90 percent noncondensing |
|
Altitude |
Designed and tested for 0 to 10,000 ft (3050m) |
|
Shock |
50G, 2 m/sec |
|
Vibration |
0.41 Grms2 (3 to 500 Hz) random input |
|
Acoustic Noise |
64.2 dBa max |
|
Temperature |
-13 to 158ºF (-25 to 70ºC) |
|
Relative Humidity |
10 to 90 percent noncondensing |
|
Altitude |
Designed and tested for 0 to 15,000 ft (4570m) |
|
Shock |
70G, 4.22 m/sec |
|
Vibration |
1.12 Grms2 (3 to 500 Hz) random input |
|
AC Range Line Voltage |
100 to 240 VAC |
|
AC Normal Line Voltage |
100 to 240 VAC |
|
AC Current |
4.85A |
|
AC Frequency |
50/60 Hz |
|
Dual-Power Supplies |
None |
|
DC Domestic Line Voltage |
-40.5 to 56 VDC (-48 VDC nominal) |
|
DC International Line Voltage |
-55 to -72 VDC (-60 VDC nominal) |
|
DC Current |
15A (maximum input) |
|
Steady State |
75W |
|
Maximum Peak |
108W |
|
Maximum Heat Dissipation |
369 BTU/hr |
|
Form Factor |
1 RU, 19-in. rack-mountable |
|
Dimensions (H x W x D) |
1.75 x 17.5 x 14.25 In (4.45 x 20.04 x 36.2 cm) |
|
Weight (with AC Power Supply) |
22.0 lb (10 kg) |
|
Safety |
IEC 60950-1: 2005, 2nd Edition EN 60950-1:2006+A11: 2009 UL 60950-1:2007, 2nd Edition; CSA C22.2 No. 60950-1-07, 2nd Edition |
|
Electromagnetic Compatibility (EMC) |
CE: EN55022 2006+A1: 2007 Class A; EN55024 1998+A1:2001+A2:2003; EN61000-3-2 2009; EN61000-3-3 2008; FCC: CFR 47, Part 15 Subpart B Class A 2010, ANSI C63.4 2009; ICES-003 ISSUE 4 FEBRUARY.2004; VCCI: V-3/2011.04; C-TICK: AS/NZS CISPR 22,2009 KC: KN22 & KN24 |
|
Industry Certifications |
In process |
