FortiWifi 61F (FWF-61F-BDL -950-12)

Mã sản phẩm

FWF-61F

Hardware Specifications

GE RJ45 WAN / DMZ Ports

2 / 1

GE RJ45 Internal Ports

5

GE RJ45 FortiLink Ports (Default)

2

Wireless Interface

Single Radio (2.4GHz/5GHz)
802.11 a/b/g/n/ac-W2

USB Ports

1

Console (RJ45)

1

Internal Storage

1 x 128 GB SSD

System Performance — Enterprise Traffic Mix

IPS Throughput

1.4 Gbps

NGFW Throughput

1 Gbps

Threat Protection Throughput

700 Mbps

System Performance

Firewall Throughput (1518 / 512 / 64 byte UDP packets)

10/10/6 Gbps

Firewall Latency (64 byte, UDP)

3.3 μs

Firewall Throughput (Packet per Second)

9 Mpps

Concurrent Sessions (TCP)

700,000

New Sessions/Sec (TCP)

35,000

Firewall Policies

5,000

IPsec VPN Throughput (512 byte)

6.5 Gbps

Gateway-to-Gateway IPsec VPN Tunnels

200

Client-to-Gateway IPsec VPN Tunnels

500

SSL-VPN Throughput

900 Mbps

Concurrent SSL-VPN Users

200

SSL Inspection Throughput (IPS, HTTP)

630 Mbps

SSL Inspection CPS (IPS, avg. HTTPS)

400

SSL Inspection Concurrent Session (IPS, avg. HTTPS)

55,000

Application Control Throughput

1.8 Gbps

CAPWAP Throughput (1444 byte, UDP)

8 Gbps

Virtual Domains (Default / Maximum)

10 / 10

Maximum Number of Switches Supported

16

Maximum Number of FortiAPs (Total / Tunnel Mode)

64 / 32

Maximum Number of FortiTokens

500

High Availability Configurations

Active / Active, Active / Passive, Clustering

Dimensions

Height x Width x Length (inches)

1.5 x 8.5 x 6.3

Height x Width x Length (mm)

38.5 x 216 x 160 mm

Weight

2.23 lbs (1.01 kg)

Form Factor

Desktop

Radio Specifications

Multiple User (MU) MIMO

3x3

Maximum Wi-Fi Speeds

1300 Mbps @ 5 GHz, 450 Mbps @ 2.4 GHz

Maximum Tx Power

20 dBm

Antenna Gain

3.5 dBi @ 5 GHz, 5 dBi @ 2.4 GHz

Operating Environment and Certifications

Power Rating

12Vdc, 3A

Power Required

Powered by External DC Power Adapter, 100–240V AC, 50–60 Hz

Maximum Current

100Vac/1.0A
240Vac/0.6A

Power Consumption (Average / Maximum)

17.5 W / 19.0 W

Heat Dissipation

64.8

Hardware plus 1 Year 24x7 FortiCare and FortiGuard UTP Bundle (FG-60F-BDL-950-12)
- Hardware: 10x GE RJ45 ports (including 7x Internal ports, 2x WAN ports, 1x DMZ port). Maximum managed FortiAPs (Total / Tunnel) 30 / 10;
- Unified (UTP) Protection (24x7 FortiCare plus Application Control, IPS, AV, Web Filtering and Antispam, FortiSandbox Cloud)

Data sheet Fortigate 60F

BTU/hr

Operating Temperature

32–104°F (0–40°C)

Storage Temperature

-31–158°F (-35–70°C)

Humidity

10–90% non-condensing

Noise Level

Fanless 0 dBA

Operating Altitude

Up to 7,400 ft (2,250 m)

Compliance

FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB

Certifications

ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN
